Aluminium Sheets Manufacturer in India
Aluminium 6063 Sheets Supplier, Aluminium 1050 Flat Sheet Exporter, ASTM B209 Aluminium Sheets Manufacturer in India
Sri Keshariya Metal is the largest Aluminium Sheets supplier in India. Our Aluminium 6063 Sheets have a very good surface finish, which finds common application in architectural purposes. We supply Aluminium Alloy 1050 CR Sheets, which are appreciated because of their high thermal conductivity and workability. Our stock of Aluminium Flat Sheet can be used in general fabrication and signage, and is strong and corrosion-resistant in most conditions.
Other Types of Aluminium Sheets
-
5mm Aluminium Flat Sheet
-
Aluminium Clad Plate
-
Aluminium Alloy UNS A91050 Sheet
-
Aluminium 1050 Flat Sheet
-
Aluminium 1050 Cold Rolled Sheet
-
Aluminium Alloy 1050 CR Sheets
-
Aluminium 2024 Sheets
-
Polished Aluminum Clad Plate
Sri Keshariya Metal
Aluminium 2024 Sheets Exporter, 5086 Aluminum Sheets Supplier,1060 Aluminium Sheets Dealer, Aluminium Sheets Supplier in India
Sri Keshariya Metal is a remarkable Aluminium Sheets supplier in India. Our Hot Rolled Aluminium Sheets are strong with structural capability and can be used for heavy-duty fabrication. Our Aluminium Industrial Sheets are evenly thick and are highly durable to give consistent results over the manufacturing setups. The Aluminium Cold-Rolled Sheets are smooth and a tight fit, which is suited to precision-based engineering projects. We are also a top quality Aluminium Round Bar Manufacturer in India.
Specifications of Aluminium Sheets
| Specifications | ASTM / ASME SB209 |
| Size | 1000 mm x 60610 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 60610 mm x 60610 mm, 60610 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grades | |
| Aluminium | 1050,1100, 2017, 7150, 7178, 7575, 2050, 7085, 2011 A92011, 2014A A92014, 2024 A92024, 2219, 5052 A95052, 5083 A95083, 5754, 6061 A96061 A86061, 6063, 6082 A96082, 7071 7020, 7050 A97050, 7075 A97075 A87075, 7175 |
Types of Aluminium Sheets
Contact us Now!!
Get in touch with Sri Keshariya Metal today for high-quality pipe fittings and flanges tailored to your industrial needs!
Aluminium Sheets Chemical Properties
| Alloy AA Designation | Si | Fe | Cu | Mn | Mg | Za | V | Ti | Cr | Other | AI (MIN) | |
| Each | total | |||||||||||
| 1050 | 0.30 | 0.40 | 0.05 | 0.05 | 0.05 | 0.10 | 0.05 | 0.03 | – | 0.03 | – | 99.5 |
| 1100 | (Fe+Si) 0.95 | 0.05 0.20 | – 0.05 | – – | – 0.10 | – – | – – | – – | – 0.5 | – 0.15 | 99.0 | |
| 1200 | (Fe+Si) 1.00 | – 0.05 | – 0.05 | – – | – 0.10 | – – | – 0.05 | – – | – 0.05 | – 0.15 | 99.0 | |
| 3003 | – 0.60 | – 0.70 | 0.05 0.20 | 1.00 1.50 | – – | – 0.10 | – – | – – | – – | – 0.05 | – 0.15 | Rem. |
| 3105 | – 0.60 | – 0.70 | – 0.30 | 0.30 0.80 | 0.20 0.80 | – 0.40 | – – | – 0.10 | – 0.20 | – 0.05 | – 0.15 | Rem. |
| 8011 | 0.60 0.95 | 0.60 0.95 | – 0.20 | – 0.10 | – 0.10 | – 0.20 | – – | – 0.20 | – 0.05 | – 0.05 | – 0.15 | Rem. |
Aluminium Sheets mechanical Properties
| Aluminium Sheets mechanical Properties | |||||
| Alloy AA Old (ISS) New (ISS) | Temper | Ultimate Strength | Tensile Kg/mm2 | 0.2% Proof Stress Kg/mm2 |
Elongation On 50 mm GL |
| Min. | Max. | ||||
| 1100[1C][19000] |
O |
– |
11.0 |
– |
25 |
| 1050[1B][19500] | O | – | 10.0 | – | 25 |
| 1060[19600] | O | – | 9.5 | – | 25 |
| 1070[19700] | O | – | 9.5 | – | 25 |
| 4043[N21][43000] | O | – | 13.0 | – | 18 |
| 4047[N2] [46000] | O | – | 15.0 | – | 12 |
| 5052[N4] [52000] | O | – | 24.5 | – | 18 |
| 5086[N5] [53000] | O | – | 26.5 | – | 16 |
| 5056[N6] [55000] | O | – | 34.5 | – | 15 |
| 5083[N8] [54300] | O | – | 35.5 | – | 13 |
Applications of Aluminium Sheets
Oil & Gas Industry
Oil & Gas Industry
Pharmaceutical Industry
Pharmaceutical Industry
Petrochemical Industries
Petrochemical Industries
Marine & Shipbuilding
Marine & Shipbuilding
Automotive Industries
Automotive Industries
The Standards We Follow while manufacturing our Aluminium Sheets:
Packaging of Aluminium Sheets
-
Gunny Bags / Woven Sacks
-
Cartons Boxes
-
Wooden Boxes
-
Plastic-Wrapped Packaging
-
Custom Packaging
-
Box Packaging
